Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    119.2
  • Torque (Nm):
    161.6
  • Valves:
    4
  • Valve Configuration:
    OHV - Pushrod
  • Bore (in):
    3.98
  • Stroke (in):
    4.45
  • Displacement (cc):
    1811
  • Compression Ratio:
    9.5:1
  • Torque RPM:
    3000
  • Fuel Injector Size (mm):
    54
• TRANSMISSION

  add remove
  • Number Of Speeds:
    6
  • Gear Ratio (1):
    9.4
  • Gear Ratio (2):
    6.41
  • Gear Ratio (3):
    4.73
  • Gear Ratio (4):
    3.8
  • Gear Ratio (5):
    3.24
  • Gear Ratio (6):
    2.79
  • Final Drive Ratio:
    2.2
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    98.7
  • Width (in):
    39.4
  • Height (in):
    54.5
  • Wheelbase (in):
    65.7
  • Dry Weight (lbs):
    795
  • Wet Weight (lbs):
    827
  • GVWR (lbs):
    1385
  • Fuel Capacity (gal):
    5.5
  • Ground Clearance (in):
    5.1
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Dunlop® American Elite: 130/60 - 19 61H
  • Rear Tire (Full Spec):
    Dunlop® Elite 3: 180/60 - 16 80H
